Aperçu Produitsplat d'acier au carbone

Grade S45C SAE1045 Cold Rolled 1.0-3.0mm 1250*2500mm Carbon Steel Sheet

Certificat
LA CHINE JIANGSU MITTEL STEEL INDUSTRIAL LIMITED certifications
LA CHINE JIANGSU MITTEL STEEL INDUSTRIAL LIMITED certifications
Examens de client
c'est le deuxième ordre l achat cette société, qualité est très bon, mêmes que la qualité .we d'europure ira sur le ccooperate avec cette société.

—— Andrew Greg - la Turquie

la feuille d'acier inoxydable de 200 tonnes est arrivée le 10 octobre 2014, la qualité est très bonne., fournissent le temps est très rapide il est très chanceuse nous trouvent cette usine

—— Cardon de Mechile Kilar - Brazial

Nous avons pour coopérer avec cette usine beaucoup d'années, tout va très Well.l comme cette usine !

—— Hilton élégant - la Pologne

C'est notre troisième achat de fois de Mittel, qualité est très des marchandises, nous sont heureux de trouver cette usine fiable

—— Natalya Ugay-Russie

La qualité est très bonne et délai de livraison très rapide, nous voulons faire de longues affaires de termes avec cette société

—— Pongpol Pluemsati-Thaïlande

Je suis en ligne une discussion en ligne

Grade S45C SAE1045 Cold Rolled 1.0-3.0mm 1250*2500mm Carbon Steel Sheet

Grade S45C  SAE1045 Cold Rolled 1.0-3.0mm 1250*2500mm Carbon Steel Sheet
Grade S45C  SAE1045 Cold Rolled 1.0-3.0mm 1250*2500mm Carbon Steel Sheet Grade S45C  SAE1045 Cold Rolled 1.0-3.0mm 1250*2500mm Carbon Steel Sheet Grade S45C  SAE1045 Cold Rolled 1.0-3.0mm 1250*2500mm Carbon Steel Sheet

Image Grand :  Grade S45C SAE1045 Cold Rolled 1.0-3.0mm 1250*2500mm Carbon Steel Sheet

Détails sur le produit:
Lieu d'origine: Chine
Nom de marque: TSING SHAN
Certification: ISO 9001
Numéro de modèle: 45 # / 1045 / S45C
Conditions de paiement et expédition:
Quantité de commande min: 500 kg
Prix: 650-780 USD/Ton
Détails d'emballage: palettes en bois
Délai de livraison: 5 - 7 jours
Conditions de paiement: T / T, Western Union, Moneygram
Capacité d'approvisionnement: 300 tonnes par mois

Grade S45C SAE1045 Cold Rolled 1.0-3.0mm 1250*2500mm Carbon Steel Sheet

description de
Produits: Plaque d'acier Grade: 45 # / 1045 / S45C
Gamme d'épaisseur: 1 à 20 mm Largeur: 1000-2500 mm ou comme demande
Longueur: Longueur personnalisée comme demande SERVICE: Coupe
Marque: Hbsc L'autre catégorie: 40CR 42CRMO Q355

Grade S45C SAE1045 Cold Rolled 1.0-3.0mm 1250*2500mm Steel Sheet



Detail informations of our 1045 Steel Plate



Product Name
 1045 Steel Plate
Width
2200mm or custom as request
Length
custom as request
Thickness 10 - 200mm
Service
Cutting plate into any size as request
Other Grade
1035 1040 1055 1060 1065 1070 1016 1037 1039 1046 1053 1566 1572 Grade 50 Grade 55 Grade 60 Grade 65 Grade 80 S35C S40C S50C S55C S58C SWRH67B SWRH72A SWRH77A 40 1040 65 1065 SWRCH22K C22E S550QL 1.8925 1.0114 1.0425 40Cr 5140
Application
Widely used in construction machinery, mining machinery, coal mining machinery, environmental protection machinery, metallurgical
machinery and other parts.Excavator, loader, bulldozer bucket plate, blade plate, side blade plate, blade.Crusher liner, blade
MOQ
500 kgs
Shipment time
5 - 7 days for mateials in stock





AISI 1045 steel is characterized by good weldability, good machinability, and high strength and impact properties in either the normalized or hot-rolled condition.

AISI 1045 steel has a low through-hardening capability with only sections of around 60 mm in size being recommended as suitable for tempering and through-hardening. However, it can be efficiently flame- or induction-hardened in the normalized or hot rolled condition to obtain surface hardnesses in the range of Rc 54 - Rc 60 based on factors such as section size, type of set up, quenching medium used etc.

AISI 1045 steel lacks suitable alloying elements and hence does not respond to the nitriding process.



Chemical composition of AISI 1045



C FE MN P S
0.420 - 0.50% 98.51 - 98.98% 0.60 - 0.90% ≤ 0.040% ≤ 0.050%



Mechanical Properties



Mechanical Properties Metric Imperial
Hardness, Brinell 163 163
Hardness, Knoop (Converted from Brinell hardness) 184 184
Hardness, Rockwell B (Converted from Brinell hardness) 84 84
Hardness, Vickers (Converted from Brinell hardness) 170 170
Tensile Strength, Ultimate 565 MPa 81900 psi
Tensile Strength, Yield 310 MPa 45000 psi
Elongation at Break (in 50 mm) 16.0 % 16.0 %
Reduction of Area 40.0 % 40.0 %
Modulus of Elasticity (Typical for steel) 200 GPa 29000 ksi
Bulk Modulus (Typical for steel) 140 GPa 20300 ksi
Poissons Ratio (Typical For Steel) 0.290 0.290
Shear Modulus (Typical for steel) 80 GPa 11600 ksi

Applications

AISI 1045 is widely used for all industrial applications requiring more wear-resistance and strength. Typical applications of AISI 1045 are as follows:

Gears Pins Rams
Shafts Rolls Sockets
Axles Spindles Worms
Bolts Ratchets Light gears
Studs Crankshafts Guide rods
Connecting rods Torsion bars Hydraulic clamps





Grade S45C  SAE1045 Cold Rolled 1.0-3.0mm 1250*2500mm Carbon Steel Sheet 0Grade S45C  SAE1045 Cold Rolled 1.0-3.0mm 1250*2500mm Carbon Steel Sheet 1Grade S45C  SAE1045 Cold Rolled 1.0-3.0mm 1250*2500mm Carbon Steel Sheet 2



Q1: What's your terms of payment?
A: 30%T/T as the upfront deposit, 70% before delivery, We will show you the photos and package before you pay the balance.
Q2: What's the terms of delivery?
A: EXW, FOB, CFR, CIF
Q3: What's the terms of packing?
A: Generally,we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers' requirement.
Q4: What's your delivery time?
A: For stocks, we could transport the goods to loading port within 7 work days after we received the deposit.For productionperiod, it usually takes about 15 days to 30 days after we received the deposit.
Q5: Could you produce according to the samples?
A: Yes, we can customer-made by your samples or technique drawings, we can build the mold and fixtures.
Q6: Could youprovide the compliment samples?
A: Yes, we could provide the free samples on condition that it is available in stocks, however,the transportation fee is borne by buyer.
Q7: How could you guarantee your products quality?
A: Each piece of products is manufactured by certified workshops, inspected by us piece by piece according to national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.
Q8:What are the advantages of your company?
A:(1): Prime quality and reasonable price.
(2): Wide excellent experiences with after-sale service.
(3): Every process will be checked by responsible QC which insures every product's quality.
(4): Professional packing teams which keep every packing safely.
(5): Trial order can be done in one week.
(6): Samples can be provided as your requirements
